The LOJ Conversions Gen III/IV Chevrolet LS Engine into M35 / M45 Basic Swap kit is the most economical engine installation package available for the 06-10 Infiniti M35 or M45 RWD. This kit has been engineered specifically for the RWD M35 or M45 to make the installation of your LS engine as simple as possible when choosing to run a GM 6L80/6L90/4L80 Transmission. Every component required to successfully bolt an LSx Gen 3 or 4 engine into your M35 is included with this kit.

This kit uses a 6L80, 6L90, or 4L80 Transmission.

**You are NOT able to use your stock Nissan Automatic Transmission with an LS Engine.

**This Kit is not compatible with AWD Configurations and will need to be converted to RWD.

The BASIC Kit Includes:

LOJ LSx to M35 Motor Mounts (CNC Cut and Bent Motor Mount Brackets, Billet Aluminum Mount Pedestals with Energy Suspension Polyurethane Inserts, Brackets are powdercoated for durability and include hardware)
LOJ M35 Swap Transmission Mount for 6L80, 6L90, or 4L80 Transmissions with Energy Suspension Transmission Mount
LOJ LSx to M35 Oil Pan (6.5 qt Capacity, Road Race Baffling, Dipstick, Pickup Tube, Gasket, Hardware.
Includes Aluminum Driveshaft (CARBON FIBER Optional; Steel not available due to length and driveshaft critical speed)

**Note: Installation of this kit with a GM Transmission WILL require modifications to the transmission tunnel to clear the bellhousing and transmission.

**Note: For 6L80 Transmissions with a 3 Bolt Flange type output there will be an additional fee
